Ubiquiti U7 Long Range - U7-LR

Price excl. tax: €147.00 287.51BGN.
Price inc. tax: €176.40 345.01BGN.
  • Code:
    U7-LR
  • Weight:
    0.500 Kgs

U7-LR is a high-performance Access Point leveraging advanced WiFi 7 technology to provide powerful wireless coverage to enterprise environments. It delivers an aggregate radio rate of up to 5.0 Gbps with 5 GHz (3x3 MU-MIMO) and 2.4 GHz 2x2 MU-MIMO radios. The U7-LR seamlessly blends into any environment.

  • Five-stream high-efficiency Wi-Fi 7 technology
  • 5 GHz band 3x3 MU-MIMO with radio rate of 4.3 Gbps
  • 2.4 GHz band 2x2 MU-MIMO with radio rate of 688 Mbps
  • Powered with 802.3af PoE / passive 43V - 57V DC
  • Managed by UniFi Network Controller version: 9.0.114 or higher
Add to wishlist

Quick Buy

Just 2 fields to fill in
We will contact you to finalize the order
New Product
Ubiquiti U7 Long Range - U7-LR
Ubiquiti U7 Long Range - U7-LR Ubiquiti U7 Long Range - U7-LR Ubiquiti U7 Long Range - U7-LR Ubiquiti U7 Long Range - U7-LR
Send to friend
Rate this product
Compliance Information
Dimensions
⌀175.7 x 43 mm (⌀6.9 x 1.7")
WiFi Standard
WiFi 7
Spatial Streams
5
Coverage Area
160 m² (1,750 ft²)
Max. Client Count
300+
Uplink
2.5 GbE
Mounting
Ceiling, Wall (Plastic Mounting Plate included)
Power Method
PoE

MIMO

5 GHz
3 x 3 (DL/UL MU-MIMO)
2.4 GHz
2 x 2 (DL/UL MU-MIMO)
Max. Data Rate

5 GHz
4.3 Gbps (BW160)
2.4 GHz
688 Mbps (BW40)
Antenna Gain

5 GHz
6 dBi
2.4 GHz
4 dBi
Max. TX Power

5 GHz
27 dBm
2.4 GHz
26 dBm
Supported Data Rates

802.11be (WiFi 7)
7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2/3, EHT 20/40/80/160)
802.11ax (WiFi 6)
7.3 Mbps to 3.6 Gbps (MCS0 - MCS11 NSS1/2/3, HE 20/40/80/160)
802.11ac (WiFi 5)
6.5 Mbps to 2.6 Gbps (MCS0 - MCS9 NSS1/2/3, VHT 20/40/80/160)
802.11n
6.5 Mbps to 450 Mbps (MCS0 - MCS23 , HT 20/40)

Wireless Meshing
✓
Band Steering
✓
802.11v BSS Transition Management
✓
802.11r Fast Roaming
✓
802.11k Radio Resource Management (RRM)
✓
Advanced Radio Management
✓
Passpoint (Hotspot 2.0)
✓
Captive Hotspot Portal

Custom Branding Landing Page
✓
Voucher Authentication
✓
Payment-Based Authentication
✓
External Portal Server Support
✓
Password Authentication
✓
Guest Network Isolation
✓
Private Pre-Shared Key (PPSK)
✓
WiFi Speed Limiting
✓
Client Device Isolation
✓
WiFi Schedules
✓
RADIUS over TLS (RadSec)
✓
Dynamic RADIUS-assigned VLAN
✓

Max. Power Consumption
14W
Includes PoE Adapter
—
Supported Voltage Range
42.5–57V DC
Networking Interface
(1) 2.5 GbE RJ45 port
Weight
448 g (15.8 oz)
Management
Ethernet
Enclosure Material
Polycarbonate, aluminum alloy
Mount Material
Polycarbonate, galvanized steel (SGCC)
LEDs

System
White/Blue
Channel Bandwidth
HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160 (MHz)
Ambient Operating Temperature
-30 to 50° C (-22 to 122° F)
Ambient Operating Humidity
5 to 95% noncondensing
NDAA Compliant
✓
Certifications
CE, FCC, IC, SRRC, Anatel: 04071-25-08356

Application Requirements

UniFi Network
Version 9.1.120 and later
Mobile App
iOS™ version 10.20.2 and later Android™ version 10.21.7 and later
